Description
A sound sensor is a module that detects sound waves by measuring their intensity and converting them to electrical signals. The sound detection sensor module for Arduino determines whether or not a threshold value has been exceeded. A microphone detects sound and feeds it into an LM393 op-amp. An onboard potentiometer is used to adjust the sound level set point. When the sound level exceeds the threshold, an LED on the module illuminates and the output is turned off. Applications like voice switch Projects and loudness level indicator.
Features
- Uses an electret condenser microphone
- Signal Output indication
- Both Analog and Digital Output are given
- The comparator output is light
- Electric condenser microphone
- Low-level output signal used for sound control light
- Its made in India
Specifications
| Working voltage | DC 3.3-5 V |
| Op-Amp IC | LM393 |
| Make | India |
| Induction distance | 0.5M |
| Board PCB Size | 35x15x13mm |
| Output Type | Both Analog and Digital |
| Trim-pot Value | 100k ohm |
| Microphone Type | Electret Condenser Microphone |
| Mic Diameter | 6mm |
| Country of Origin | China |
