Description
The 10E271 Metal Oxide Varistors are semiconductors whose resistance changes from a very high open circuit condition to a deficient short circuit condition to clamp any surge or voltage transient in an electrical circuit. It's used in Protection for semiconductors such as a transistor, diode, IC, thyristor, or TRAIC Relay and electromagnetic valve surge absorption, Surge protection in consumer electronics, Surge protection in industrial electronics, Surge protection in electronic household appliances, gas and petroleum appliances.
Features
-
It's used as a protection circuit device
- Low clamping ratio and no following-on current
- Extensive absorbing transient energy capability.
- Fast responding to transient over-voltage
Specification
| Model | 10E271 |
| Type | Varistor |
| Voltage | 180Vac RMS |
| Operating temperature | -40 to 85-degree centigrade |
| Material storage temperature | -40 to 125-degree centigrade |
| Body | Nickel plated |
| Tolerance | -20 to +20 % |
| Operating surface temperature | 25°C |
| Country of Origin | China |
