Description
- Input voltage :6-35V
- Output voltage: 6-55V (adjustable)
- Output Current: 10A (MAX)
- Input Current: 7A (MAX)
- The non-isolated step-up power conversion module
- Onboard LED illuminates when the voltage is applied to the module
- Equips Multi-turn Potentiometer.
| Max. Output Current (A) |
7 |
|---|---|
| Output Power(Watt) |
200 |
| Conversion Efficiency(%) |
97.6 |
| Operating Temperature (°C): |
-10 to 60 |
| Length (mm): |
70 |
| Width (mm): |
39 |
| Height (mm): |
32 |
| Weight (g): |
65 |
| Shipping Weight | 0.07 kg |
| Shipping Dimensions | 9 × 5 × 3 cm |
