Description
- Maximum Output Current: 3A MAX
- Conversion efficiency: can up to 97.5%
- Switch frequency: 500KHz
- Output Ripple: 10mV around (12V to 5V3A) 20M bandwidth
- Output indicator: Output voltage indicator is red
- Operating temperature: Industrial grade (-40 ° to + 85 °)
- Output overvoltage protection: Yes, input 1.5A fuse, output 5V have 300W TVS tube clamp protection.
- Flat copper inductor, improve conversion efficiency
- High-quality USB port
| Maximum Output Current |
3A |
|---|---|
| Maximum Conversion Efficiency |
97.5% |
| Full load temperature |
30 °C |
| Switching Frequency |
500KHz |
| Load Regulation |
±1% |
| Voltage Regulation |
±0.5% |
| Dynamic Response Speed |
5% 200uS |
| Dimensions(LxWxH)mm |
26.4 x 15 x 7.4 |
| Weight (g) |
9 |
| Static current |
0.85 mA |
| Shipping Weight | 0.014 kg |
| Shipping Dimensions | 4 × 3 × 1 cm |
