Description
The ALL mXTENDTM chip antenna component was made specifically to provide multi-band performance in mobile applications‚ such as LTE‚ which enables worldwide coverage at 698 to 960 MHz and 1710 to 2690 MHz. It is used‚ among other things‚ to design Sharkfin and Smart Meters that can use all mobile communication standards.
For more detail Datasheet
Features:
- It provides high performance
- It has multiband features like 2G‚3G‚4G LTE etc.
- Its multiband feature makes it global reach.
| Specifications | |
|---|---|
| Part Number | NN02-220 |
| Type | Antenna |
| Range | 698MHz ~ 2.69GHz |
| Dimension | 24.0 mm x 12.0 mm x 2.0 mm |
| Frequency Range | 698MHz ~ 2.69GHz |
| Impedance | 50 Ohm |
| Brand | Ignion |
