Mornsun LI100-20B48PR2 AC/DC 100W DIN-Rail Power Supply

Mornsun LI100-20B48PR2 AC/DC 100W DIN-Rail Power Supply

The LI100-20B48PR2 is a cost-effective, energy-efficient AC-DC converter from Mornsun. It is a lightweight AC-DC converter with an extremely compact design for space saving.

It is compliant with international IEC62368 standards for EMC and is safety approved to IEC/EN61000-4, CISPR32, EN55032, UL62368, IEC62368 and EN62368. It has a high level of stability and immunity to noise, and is ideal for applications such as industrial control equipment, machinery, and all kinds of applications in a harsh environment.

Features

• Cost-effective
• Energy efficient
• Compliant with international IEC62368 standards for EMC
• Safety approved to IEC/EN61000-4, CISPR32, EN55032, UL62368, IEC62368 and EN62368
• High level of stability and immunity to noise
• Ideal for applications such as industrial control equipment, machinery, and all kinds of applications in a harsh environment

If you are looking for a cost-effective, energy-efficient AC-DC converter with a high level of stability and immunity to noise, the LI100-20B48PR2 is a great option. It is ideal for a variety of applications, including industrial control equipment, machinery, and all kinds of applications in a harsh environment.

check out : Mornsun LI100-20B24PR2 AC/DC 100W DIN-Rail Power Supply

Note:

• Unless otherwise specified, parameters in this datasheet were measured under the conditions of Ta=25℃, humidity<75%RH with nominal input voltage and rated output load
• The room temperature derating of 5℃/1000m is needed for operating altitude greater than 2000m
• All index testing methods in this datasheet are based on our company's corporate standards
• In order to improve the efficiency at high input voltage, there will be audible noise generated, but it does not affect product performance and reliability
• The out case needs to be connected to the earth ( )of system when the terminal equipment in operating
• The output voltage can be adjusted by the ADJ, clockwise to increase
• Our products shall be classified according to ISO14001 and related environmental laws and regulations and shall be handled by qualified units
• The power supply is considered a component which will be installed into the final equipment. All EMC tests should be confirmed with the final equipment

Package Includes:

1 x  Mornsun LI100-20B48PR2 AC/DC 100W DIN-Rail Power Supply

Specifications:
