Description
Mornsun LM450-12B48 AC/DC 450W Enclosed SMPS
The LM450-12B48 series is a line of enclosed AC-DC switching power supplies from Mornsun. They feature a wide input voltage range, AC or DC input, cost-effectiveness, high efficiency, high reliability, and excellent EMC performance. They meet a variety of safety standards, including IEC/EN61000-4, CISPR32/EN55032, UL/EN/IEC62368, and GB4943. The LM450-12B48 series is widely used in a variety of applications, including industrial, LED, street light control, electricity, security, telecommunications, and smart home.
check out : Mornsun LM600-12B48 AC/DC 600W Enclosed SMPS
Note:
- Unless otherwise specified, parameters in this datasheet were measured under the conditions of Ta=25℃, humidity<75%RH with nominal input voltage and rated output load
- The room temperature derating of 5℃/1000m is needed for operating altitude greater than 2000m
- All index testing methods in this datasheet are based on our company's corporate standards
- In order to improve the efficiency at high input voltage, there will be audible noise generated, but it does not affect product performance and reliability
- The out case needs to be connected to the earth ( )of system when the terminal equipment in operating
- The output voltage can be adjusted by the ADJ, clockwise to increase
- Our products shall be classified according to ISO14001 and related environmental laws and regulations and shall be handled by qualified units
- The power supply is considered a component which will be installed into the final equipment. All EMC tests should be confirmed with the final equipment
Package Includes:
1 x Mornsun LM450-12B48 AC/DC 450W Enclosed SMPS
Specifications:
Type | Enclosed Type Single Output |
Output Power | 451.2W |
Series | LM450-12B |
Part Number | LM450-12B48 |
Mechanical Form | Enclosed |
IP Level | Non-Waterproof |
Output Voltage | 48V |
Output Current |
9.4A |
