Description
This Raspberry Pi 3 Model A+ is a 1.4GHz 64-bit quad-core processor, dual-band wireless LAN, Bluetooth 4.2/BLE in the same mechanical format as the Raspberry Pi 1 Model A+. Its a compact single-board computer developed by the Raspberry Pi Foundation. It is a smaller and more cost-effective version of the Raspberry Pi 3 Model B+.
The Raspberry Pi 3 Model A+ is designed for projects that require a smaller form factor and lower power consumption. It is suitable for applications such as IoT (Internet of Things) devices, embedded systems, portable projects, and more.
-
Processor: The Raspberry Pi 3 Model A+ is powered by a 1.4 GHz quad-core ARM Cortex-A53 processor. This processor provides good performance for various tasks.
-
RAM: It is equipped with 512 MB of LPDDR2 SDRAM, which is slightly lower than the RAM of the Raspberry Pi 3B+.
-
Connectivity: The Model A+ offers built-in Wi-Fi 802.11b/g/n and Bluetooth 4.2, allowing for wireless connectivity options for internet access and connecting peripherals.
-
Storage: Similar to other Raspberry Pi models, it features a microSD card slot for storage. You can insert a microSD card to boot the operating system and store your files.
-
USB Ports: The Raspberry Pi 3 Model A+ has one USB 2.0 port, allowing you to connect peripherals such as a keyboard, mouse, or external storage device. However, it has fewer USB ports compared to the Model B+.
-
GPIO Pins: It includes a 40-pin General Purpose Input/output (GPIO) header, allowing for the connection of various external components and expansion boards, similar to other Raspberry Pi models.
-
Video Output: The board has a full-size HDMI port, enabling you to connect it to a monitor or TV for display.
-
Power: The board requires a 5V micro USB power supply to operate, similar to other Raspberry Pi models.
Features
- Broadcom BCM2837B0, Cortex-A53 (ARMv8) 64-bit SoC @ 1.4GHz
- 512MB LPDDR2 SDRAM
- 2.4GHz and 5GHz IEEE 802.11.b/g/n/ac wireless LAN, Bluetooth 4.2/BLE
- Extended 40-pin GPIO header
- Full-size HDMI®
- Single USB 2.0 ports
- CSI camera port for connecting a Raspberry Pi Camera
- DSI display port for connecting a Raspberry Pi Touch Display
- 4-pole stereo output and composite video port
- Micro SD port for loading your operating system and storing data
- 5V/2.5A DC power input
