Description
SP108e controller support WS2811, WS2812B, WS2801, WS2815, SK6812, WS2813, SK9822, APA102C etc. SP108E WiFi LED Controller is an App controlled LED driver which supports two modes of connections; Routing Mode (AP) and LAN Connection Mode (STA). It supports almost every type of one-wire or two-wire LED driver IC. Brightness adjustable with 180 kinds of patterns and 8 kinds of colour adjustable patterns. Creatively using the from-image-to-effect method for a user to DIY any effect. It also supports the setting of pixel number and segments number, controlling up to 2048 pixels. SP108E WiFi LED Controller operates on a wide voltage range from DC 5V to 24V and also provides reverse connection protection of the power supply. LedShop App used to control the SP108E WiFi LED Controller via smartphone, It has both Android OS and IOS versions available.
Specifications
| Working Voltage | 5V-24V DC |
| Working Current | 20mA~40mA |
| Remote Distance | 30 meters |
| Operating Temperature | -20°C to 60°C |
| Dimension | 80mmx41mmx20mm |
| Product Weight | 40g |
| Country of Origin | China |
