Introducing the Flywoo Nin V2 2303.5 – 3000KV, a single unit engineered to redefine the boundaries of FPV flight. Crafted with precision and performance in mind, this motor is designed to deliver unparalleled power, agility, and reliability.
At the heart of the Nin V2 2303.5 – 3000KV motor lies a high-performance 3000KV stator, meticulously engineered to provide exceptional thrust and speed. With its high RPM capability, this motor unleashes a torrent of power that propels your drone with exhilarating acceleration and responsiveness, perfect for racing and freestyle maneuvers alike.
Features:
- High-Performance Stator
- High RPM Capability
- Sleek and Aerodynamic Design
- Optimized Performance
- Compact and Lightweight Construction
- Smooth and Reliable Operation
Specifications:
- Configu-ration :12N14P
- Stator Diamter : 23mm
- Stator Length : 3.5mm
- Shaft Diameter : 3mm(in) 1.5mm(out)
- Motor Dimension(Dia.*Len) : Φ29.1*13.5mm
- Weight(g) : 21.5（3cm Wire）
- Idle current(10) @10V(A) : 1.25
- No.of Cells(Lipo) : 3~4S
- Max Continuous Power(W) 3S : 656
- Internal Resistance : 71mΩ
- Max Current(3S) : 41A
- Max.Effciency Current : (2.5-5A)>85%
Package Includes:
1 x Flywoo Nin V2 2303.5 – 3000KV 1 PC
