The U200 V2 is a high-performance Brushless DC (BLDC) motor speed controller designed for 5 to 14S LiPo batteries. With a continuous current rating of 200A and a peak current of 240A, it’s optimized for demanding applications like powered paragliders. Weighing approximately 320g and featuring robust 8 AWG power and motor lines, this Brushless DC Motor Automatic Electric Speed Controller ensures excellent efficiency under good cooling conditions.
Features:
- Protective Functions: Short circuit, stall, voltage, temperature, and throttle loss protections enhance safety.
- Throttle Range: Adjustable throttle pulse width (1050us-1940us) compatible with 3.3V/5V input signals.
- Communication: RS-485 interface for seamless integration with flight controllers.
- Environmental Rating: IP67-rated for protection against dust and water.
Specifications:
- Size: 117.5 x 56.3 x 42.8 mm
- Weight: 320g (excluding wires)
- Operating Temperature: -25 to 60°C
- Current Limiting: 200A
- Recommended Battery: 12S
- Signal Frequency: 50-500Hz
Package include:
1 x XC ESC – 12s 200A 48V 13HP Powered Paraglider Brushless DC Motor Automatic Electric Speed Controller
